turtle画哆啦A梦(不止一个哦 多个有趣的画)

2021/2/6 23:24:08 文章标签: 测试文章如有侵权请发送至邮箱809451989@qq.com投诉后文章立即删除

有趣的turtle库前言彩色螺旋线效果太阳花效果国旗效果玫瑰花效果彩色树效果随机樱花树效果圆舞曲效果哆啦A梦效果时钟效果前言 听说有人找画哆啦A梦的源码。分享python turtle库 几个有趣的源码彩色螺旋线 from turtle import * speed(9) # 画笔速度 pensize(2) …

有趣的turtle库

      • 前言
      • 彩色螺旋线
        • 效果
      • 太阳花
        • 效果
      • 国旗
        • 效果
      • 玫瑰花
        • 效果
      • 彩色树
        • 效果
      • 随机樱花树
        • 效果
      • 圆舞曲
        • 效果
      • 哆啦A梦
        • 效果
      • 时钟
        • 效果

前言

听说有人找画哆啦A梦的源码。分享python turtle库 几个有趣的源码



彩色螺旋线

from turtle import *
speed(9)            # 画笔速度
pensize(2)			# 画笔的宽度
bgcolor("black")		# 画布背景色
colors = ["red","yellow","purple","blue"]	# 定义画笔线色
for x in range(400):		# 循环一次 画一条线
    forward(2*x) 	        # 向当前方向前进n像素
    color(colors[x % 4])	# 根据求余 调整画笔线色
    left(91)                # 向左旋转91度

mainloop()

效果



太阳花

import turtle
turtle=turtle.Turtle()
screen=turtle.getscreen()
turtle.color('red', 'yellow')
turtle.begin_fill()
for i in range(50):
    turtle.forward(200)
    turtle.left(170)
turtle.end_fill()
turtle.done()

效果

在这里插入图片描述


国旗

from turtle import *

screensize(2000, 2000, 'white')  # 设置画布大小
speed(9)
# 绘制旗面
pencolor('red')
# pu()
goto(-300, -200)
pd()
fillcolor('red')
begin_fill()
for i in range(0, 2):
    fd(600)
    lt(90)
    fd(400)
    lt(90)
end_fill()

# 绘制大五角星
pu()
pencolor('yellow')
goto(-260, 120)
pd()
fillcolor('yellow')
begin_fill()
for i in range(0, 5):
    fd(113.137)  # 大星一划的边长
    rt(144)
end_fill()

# 绘制四个小五角星
list1 = [(-100, 160), (-60, 120), (-60, 60), (-100, 20)]  # 四个五角星的中心坐标
list2 = [31.98, 8.13, -15.59, -38.66]  # 相对角度0的后退1.111需要左转的角度

for j in range(0, 4):
    seth(0)  # 这是龟头角度为0
    pu()
    goto(list1[j])  # 定位到五角星中心
    lt(list2[j])  # 旋转角度,以背向指向大五角星的角尖
    bk(20)  # 从五角星中心到指向大五角星的角尖(龟倒着爬)退一个小圆半径
    lt(18)  # 五角星的半角角度
    pd()
    begin_fill()
    for i in range(0, 5):
        fd(113.137 / 3)  # 小星一划的边长
        rt(144)
    end_fill()
pu()
ht()
done()

效果



玫瑰花

import turtle
import time
turtle.speed(5)
# 设置初始位置
turtle.penup()
turtle.left(90)
turtle.fd(200)
turtle.pendown()
turtle.right(90)
# 花蕊
turtle.fillcolor("red")
turtle.begin_fill()
turtle.circle(10,180)
turtle.circle(25,110)
turtle.left(50)
turtle.circle(60,45)
turtle.circle(20,170)
turtle.right(24)
turtle.fd(30)
turtle.left(10)
turtle.circle(30,110)
turtle.fd(20)
turtle.left(40)
turtle.circle(90,70)
turtle.circle(30,150)
turtle.right(30)
turtle.fd(15)
turtle.circle(80,90)
turtle.left(15)
turtle.fd(45)
turtle.right(165)
turtle.fd(20)
turtle.left(155)
turtle.circle(150,80)
turtle.left(50)
turtle.circle(150,90)
turtle.end_fill()

# 花瓣1
turtle.left(150)
turtle.circle(-90,70)
turtle.left(20)
turtle.circle(75,105)
turtle.setheading(60)
turtle.circle(80,98)
turtle.circle(-90,40)

# 花瓣2
turtle.left(180)
turtle.circle(90,40)
turtle.circle(-80,98)
turtle.setheading(-83)

# 叶子1
turtle.fd(30)
turtle.left(90)
turtle.fd(25)
turtle.left(45)
turtle.fillcolor("green")
turtle.begin_fill()
turtle.circle(-80,90)
turtle.right(90)
turtle.circle(-80,90)
turtle.end_fill()
turtle.right(135)
turtle.fd(60)
turtle.left(180)
turtle.fd(85)
turtle.left(90)
turtle.fd(80)

# 叶子2
turtle.right(90)
turtle.right(45)
turtle.fillcolor("green")
turtle.begin_fill()
turtle.circle(80,90)
turtle.left(90)
turtle.circle(80,90)
turtle.end_fill()
turtle.left(135)
turtle.fd(60)
turtle.left(180)
turtle.fd(60)
turtle.right(90)
turtle.circle(200,60)
turtle.done()

效果



彩色树

# 这个比较复杂,画的时间较长

from turtle import *
# 设置色彩模式是RGB:
colormode(255)
lt(90)
lv = 14
l = 120
s = 45
width(lv)
# 初始化RGB颜色:
r = 0
g = 0
b = 0
pencolor(r, g, b)
penup()
bk(l)
pendown()
fd(l)
def draw_tree(l, level):
    global r, g, b
    # save the current pen width
    w = width()
    # narrow the pen width
    width(w * 3.0 / 4.0)
    # set color:
    r = r + 1
    g = g + 2
    b = b + 3
    pencolor(r % 200, g % 200, b % 200)
    l = 3.0 / 4.0 * l
    lt(s)
    fd(l)
    if level < lv:
        draw_tree(l, level + 1)
    bk(l)
    rt(2 * s)
    fd(l)
    if level < lv:
        draw_tree(l, level + 1)
    bk(l)
    lt(s)
    # restore the previous pen width
    width(w)
speed("fastest")
draw_tree(l, 4)
done()

效果

在这里插入图片描述



随机樱花树

# 每次运行 树的形状是随机的
import turtle as T
import random
import time

# 画樱花的躯干(60,t)
def Tree(branch, t):
    time.sleep(0.0005)
    if branch > 3:
        if 8 <= branch <= 12:
            if random.randint(0, 2) == 0:
                t.color('snow')  # 白
            else:
                t.color('lightcoral')  # 淡珊瑚色
            t.pensize(branch / 3)
        elif branch < 8:
            if random.randint(0, 1) == 0:
                t.color('snow')
            else:
                t.color('lightcoral')  # 淡珊瑚色
            t.pensize(branch / 2)
        else:
            t.color('sienna')  # 赭(zhě)色
            t.pensize(branch / 10)  # 6
        t.forward(branch)
        a = 1.5 * random.random()
        t.right(20 * a)
        b = 1.5 * random.random()
        Tree(branch - 10 * b, t)
        t.left(40 * a)
        Tree(branch - 10 * b, t)
        t.right(20 * a)
        t.up()
        t.backward(branch)
        t.down()

# 掉落的花瓣
def Petal(m, t):
    for i in range(m):
        a = 200 - 400 * random.random()
        b = 10 - 20 * random.random()
        t.up()
        t.forward(b)
        t.left(90)
        t.forward(a)
        t.down()
        t.color('lightcoral')  # 淡珊瑚色
        t.circle(1)
        t.up()
        t.backward(a)
        t.right(90)
        t.backward(b)

# 绘图区域
t = T.Turtle()
# 画布大小
w = T.Screen()
t.hideturtle()  # 隐藏画笔
t.getscreen().tracer(5, 0)
w.screensize(bg='wheat')  # wheat小麦
t.left(90)
t.up()
t.backward(150)
t.down()
t.color('sienna')

# 画樱花的躯干
Tree(60, t)
# 掉落的花瓣
Petal(200, t)
w.exitonclick()
T.done()

效果

在这里插入图片描述



圆舞曲

from turtle import *

def stop():
    global running
    running = False

def main():
    global running
    clearscreen()
    bgcolor("gray10")
    tracer(False)
    shape("triangle")
    f =   0.793402
    phi = 9.064678
    s = 5
    c = 1
    # create compound shape
    sh = Shape("compound")
    for i in range(10):
        shapesize(s)
        p =get_shapepoly()
        s *= f
        c *= f
        tilt(-phi)
        sh.addcomponent(p, (c, 0.25, 1-c), "black")
    register_shape("multitri", sh)
    # create dancers
    shapesize(1)
    shape("multitri")
    pu()
    setpos(0, -200)
    dancers = []
    for i in range(180):
        fd(7)
        tilt(-4)
        lt(2)
        update()
        if i % 12 == 0:
            dancers.append(clone())
    home()
    # dance
    running = True
    onkeypress(stop)
    listen()
    cs = 1
    while running:
        ta = -4
        for dancer in dancers:
            dancer.fd(7)
            dancer.lt(2)
            dancer.tilt(ta)
            ta = -4 if ta > 0 else 2
        if cs < 180:
            right(4)
            shapesize(cs)
            cs *= 1.005
        update()
    return "DONE!"

if __name__=='__main__':
    print(main())
    mainloop()

效果

在这里插入图片描述



哆啦A梦

import turtle


def flyTo(x, y):
    turtle.penup()
    turtle.goto(x, y)
    turtle.pendown()
def drawEye():
    turtle.tracer(False)
    a = 2.5
    for i in range(120):
        if 0 <= i < 30 or 60 <= i < 90:
            a -= 0.05
        else:
            a += 0.05
        turtle.left(3)
        turtle.fd(a)
    turtle.tracer(True)
def beard():
    """ 画胡子, 一共六根
    """
    # 左边第一根胡子
    flyTo(-37, 135)
    turtle.seth(165)
    turtle.fd(60)
    # 左边第二根胡子
    flyTo(-37, 125)
    turtle.seth(180)
    turtle.fd(60)
    # 左边第三根胡子
    flyTo(-37, 115)
    turtle.seth(193)
    turtle.fd(60)
    # 右边第一根胡子
    flyTo(37, 135)
    turtle.seth(15)
    turtle.fd(60)
    # 右边第二根胡子
    flyTo(37, 125)
    turtle.seth(0)
    turtle.fd(60)
    # 右边第三根胡子
    flyTo(37, 115)
    turtle.seth(-13)
    turtle.fd(60)
def drawRedScarf():
    """ 画围巾
    """
    turtle.fillcolor("red")  # 填充颜色
    turtle.begin_fill()
    turtle.seth(0)  # 朝向右
    turtle.fd(200)  # 前进10个单位
    turtle.circle(-5, 90)
    turtle.fd(10)
    turtle.circle(-5, 90)
    turtle.fd(207)
    turtle.circle(-5, 90)
    turtle.fd(10)
    turtle.circle(-5, 90)
    turtle.end_fill()
def drawMouse():
    flyTo(5, 148)
    turtle.seth(270)
    turtle.fd(100)
    turtle.seth(0)
    turtle.circle(120, 50)
    turtle.seth(230)
    turtle.circle(-120, 100)
def drawRedNose():
    flyTo(-10, 158)
    turtle.fillcolor("red")  # 填充颜色
    turtle.begin_fill()
    turtle.circle(20)
    turtle.end_fill()
def drawBlackdrawEye():
    turtle.seth(0)
    flyTo(-20, 195)
    turtle.fillcolor("#000000")  # 填充颜色
    turtle.begin_fill()
    turtle.circle(13)
    turtle.end_fill()
    turtle.pensize(6)
    flyTo(20, 205)
    turtle.seth(75)
    turtle.circle(-10, 150)
    turtle.pensize(3)
    flyTo(-17, 200)
    turtle.seth(0)
    turtle.fillcolor("#ffffff")
    turtle.begin_fill()
    turtle.circle(5)
    turtle.end_fill()
    flyTo(0, 0)
def drawFace():
    turtle.forward(183)  # 前行183个单位
    turtle.fillcolor("white")  # 填充颜色为白色
    turtle.begin_fill()  # 开始填充
    turtle.left(45)  # 左转45度
    turtle.circle(120, 100)  # 右边那半边脸
    turtle.seth(90)  # 朝向向上
    drawEye()  # 画右眼睛
    turtle.seth(180)  # 朝向左
    turtle.penup()  # 抬笔
    turtle.fd(60)  # 前行60
    turtle.pendown()  # 落笔
    turtle.seth(90)  # 朝向上
    drawEye()  # 画左眼睛
    turtle.penup()  # 抬笔
    turtle.seth(180)  # 朝向左
    turtle.fd(64)  # 前进64
    turtle.pendown()  # 落笔
    turtle.seth(215)  # 修改朝向
    turtle.circle(120, 100)  # 左边那半边脸
    turtle.end_fill()  #
def drawHead():
    """ 画了一个被切掉下半部分的圆
    """
    turtle.penup()  # 抬笔
    turtle.circle(150, 40)  # 画圆, 半径150,圆周角40
    turtle.pendown()  # 落笔
    turtle.fillcolor("#00a0de")  # 填充色
    turtle.begin_fill()  # 开始填充
    turtle.circle(150, 280)  # 画圆,半径150, 圆周角280
    turtle.end_fill()
def drawAll():
    drawHead()
    drawRedScarf()
    drawFace()
    drawRedNose()
    drawMouse()
    beard()
    flyTo(0, 0)
    turtle.seth(0)
    turtle.penup()
    turtle.circle(150, 50)
    turtle.pendown()
    turtle.seth(30)
    turtle.fd(40)
    turtle.seth(70)
    turtle.circle(-30, 270)
    turtle.fillcolor("#00a0de")
    turtle.begin_fill()
    turtle.seth(230)
    turtle.fd(80)
    turtle.seth(90)
    turtle.circle(1000, 1)
    turtle.seth(-89)
    turtle.circle(-1000, 10)
    turtle.seth(180)
    turtle.fd(70)
    turtle.seth(90)
    turtle.circle(30, 180)
    turtle.seth(180)
    turtle.fd(70)
    turtle.seth(100)
    turtle.circle(-1000, 9)
    turtle.seth(-86)
    turtle.circle(1000, 2)
    turtle.seth(230)
    turtle.fd(40)
    turtle.circle(-30, 230)
    turtle.seth(45)
    turtle.fd(81)
    turtle.seth(0)
    turtle.fd(203)
    turtle.circle(5, 90)
    turtle.fd(10)
    turtle.circle(5, 90)
    turtle.fd(7)
    turtle.seth(40)
    turtle.circle(150, 10)
    turtle.seth(30)
    turtle.fd(40)
    turtle.end_fill()
    # 左手
    turtle.seth(70)
    turtle.fillcolor("#FFFFFF")
    turtle.begin_fill()
    turtle.circle(-30)
    turtle.end_fill()
    # 脚
    flyTo(103.74, -182.59)
    turtle.seth(0)
    turtle.fillcolor("#FFFFFF")
    turtle.begin_fill()
    turtle.fd(15)
    turtle.circle(-15, 180)
    turtle.fd(90)
    turtle.circle(-15, 180)
    turtle.fd(10)
    turtle.end_fill()
    flyTo(-96.26, -182.59)
    turtle.seth(180)
    turtle.fillcolor("#FFFFFF")
    turtle.begin_fill()
    turtle.fd(15)
    turtle.circle(15, 180)
    turtle.fd(90)
    turtle.circle(15, 180)
    turtle.fd(10)
    turtle.end_fill()
    # 右手
    flyTo(-133.97, -91.81)
    turtle.seth(50)
    turtle.fillcolor("#FFFFFF")
    turtle.begin_fill()
    turtle.circle(30)
    turtle.end_fill()
    # 口袋
    flyTo(-103.42, 15.09)
    turtle.seth(0)
    turtle.fd(38)
    turtle.seth(230)
    turtle.begin_fill()
    turtle.circle(90, 260)
    turtle.end_fill()
    flyTo(5, -40)
    turtle.seth(0)
    turtle.fd(70)
    turtle.seth(-90)
    turtle.circle(-70, 180)
    turtle.seth(0)
    turtle.fd(70)
    # 铃铛
    flyTo(-103.42, 15.09)
    turtle.fd(90)
    turtle.seth(70)
    turtle.fillcolor("#ffd200")
    turtle.begin_fill()
    turtle.circle(-20)
    turtle.end_fill()
    turtle.seth(170)
    turtle.fillcolor("#ffd200")
    turtle.begin_fill()
    turtle.circle(-2, 180)
    turtle.seth(10)
    turtle.circle(-100, 22)
    turtle.circle(-2, 180)
    turtle.seth(180 - 10)
    turtle.circle(100, 22)
    turtle.end_fill()
    flyTo(-13.42, 15.09)
    turtle.seth(250)
    turtle.circle(20, 110)
    turtle.seth(90)
    turtle.fd(15)
    turtle.dot(10)
    flyTo(0, -150)
    drawBlackdrawEye()
def main():
    turtle.screensize(800, 6000, "#F0F0F0")
    turtle.pensize(3)
    turtle.speed(9)
    drawAll()
if __name__ == "__main__":
    main()
    turtle.mainloop()



效果

在这里插入图片描述



时钟


import turtle
from datetime import *

# 抬起画笔,向前运动一段距离放下
def Skip(step):
    turtle.penup()
    turtle.forward(step)
    turtle.pendown()


def mkHand(name, length):
    # 注册Turtle形状,建立表针Turtle
    turtle.reset()
    Skip(-length * 0.1)
    # 开始记录多边形的顶点。当前的乌龟位置是多边形的第一个顶点。
    turtle.begin_poly()
    turtle.forward(length * 1.1)
    # 停止记录多边形的顶点。当前的乌龟位置是多边形的最后一个顶点。将与第一个顶点相连。
    turtle.end_poly()
    # 返回最后记录的多边形。
    handForm = turtle.get_poly()
    turtle.register_shape(name, handForm)


def Init():
    global secHand, minHand, hurHand, printer
    # 重置Turtle指向北
    turtle.mode("logo")
    # 建立三个表针Turtle并初始化
    mkHand("secHand", 135)
    mkHand("minHand", 125)
    mkHand("hurHand", 90)
    secHand = turtle.Turtle()
    secHand.shape("secHand")
    minHand = turtle.Turtle()
    minHand.shape("minHand")
    hurHand = turtle.Turtle()
    hurHand.shape("hurHand")

    for hand in secHand, minHand, hurHand:
        hand.shapesize(1, 1, 3)
        hand.speed(0)

    # 建立输出文字Turtle
    printer = turtle.Turtle()
    # 隐藏画笔的turtle形状
    printer.hideturtle()
    printer.penup()


def SetupClock(radius):
    # 建立表的外框
    turtle.reset()
    turtle.pensize(7)
    for i in range(60):
        Skip(radius)
        if i % 5 == 0:
            turtle.forward(20)
            Skip(-radius - 20)

            Skip(radius + 20)
            if i == 0:
                turtle.write(int(12), align="center", font=("Courier", 14, "bold"))
            elif i == 30:
                Skip(25)
                turtle.write(int(i / 5), align="center", font=("Courier", 14, "bold"))
                Skip(-25)
            elif (i == 25 or i == 35):
                Skip(20)
                turtle.write(int(i / 5), align="center", font=("Courier", 14, "bold"))
                Skip(-20)
            else:
                turtle.write(int(i / 5), align="center", font=("Courier", 14, "bold"))
            Skip(-radius - 20)
        else:
            turtle.dot(5)
            Skip(-radius)
        turtle.right(6)


def Week(t):
    week = ["星期一", "星期二", "星期三", "星期四", "星期五", "星期六", "星期日"]
    return week[t.weekday()]


def Date(t):
    y = t.year
    m = t.month
    d = t.day
    return "%s-%d-%d" % (y, m, d)


def Tick():
    # 绘制表针的动态显示
    t = datetime.today()
    second = t.second + t.microsecond * 0.000001
    minute = t.minute + second / 60.0
    hour = t.hour + minute / 60.0
    secHand.setheading(6 * second)
    minHand.setheading(6 * minute)
    hurHand.setheading(30 * hour)

    turtle.tracer(False)
    printer.forward(65)
    printer.write(Week(t), align="center", font=("Courier", 14, "bold"))
    printer.back(130)
    printer.write(Date(t), align="center", font=("Courier", 14, "bold"))
    printer.home()
    turtle.tracer(True)

    # 100ms后继续调用tick
    turtle.ontimer(Tick, 100)


def main():
    # 打开/关闭龟动画,并为更新图纸设置延迟。
    turtle.tracer(False)
    Init()
    SetupClock(160)
    turtle.tracer(True)
    Tick()
    turtle.done()


if __name__ == "__main__":
    main()


效果

在这里插入图片描述


本文链接: http://www.dtmao.cc/news_show_2000158.shtml

附件下载

相关教程

    暂无相关的数据...

共有条评论 网友评论

验证码: 看不清楚?
